LoRaWAN®-Based Waste Bin Detector
This LW006-WB sensor is designed for waste bin (trash bin) status detection. It detect full/empty, flame risk, inclined (fall) or not and etc.
With LoRaWAN® module, it transmit the status via gateway to networks server and application server. User can monitor the status remotely.
With the application software, user can assign the collector resource work plan and route plan. Analyze task performance and find out solution to improve. Finally the objective of high efficiency , good environment, and low cost are achieved. It is optional for different frequency, such as 470Mhz (Cina), 868Mhz (Europa), 915Mhz(Stati Uniti d'America), 923Mhz (Australia,New Zealand). As it is with algorithm of low power consumption, the internal battery can work for more than 5 anni (a 4 hours interval upload interval).
Ultrasonic @ 112kHz
Accuracy of height
Accuracy of temperature
Accuracy of angel
STM32, 32bit ARM® core controller
-137dbm@292bps (RX), 5~20dbm(Tx)
Modalità di lavoro
3km in view sight;
Lifetime for one charge
5 years at 4 hours report interval.
ER18505M non-recharged Lithium Battery
-40 ~ +85℃
