MKL68BA

LoRaWAN Module

MKL68BA is a standard LoRaWAN node module designed and manufactured by MOKO technology Ltd. The module integrates with the world-leading Nordic Semiconductor nRF52832 (BLE) and Semtech LLCC68 (LoRa) chipsets, providing ultra-low power consumption with excellent cost performance using the LoRa radio link and local BLE connections.

• Higher cost performance compared to MKL62BA
• More suitable for LoRaWAN communication scenarios in close proximity, such as smart water meters

Product Features

> Built-in LoRaWAN standard protocol and supports the whole world LoRaWAN frequency band
> Bluetooth v4.2 – Nordic nRF52832
> On-board BLE ceramic antenna
> U.FL for external LoRa antenna
> Built-in TCXO for improve high frequency stability

> Supports AT command for configuring
> Compact footprint and 33 pins with SMT package
> BLE TX power default in 0 dBm
> BLE RX sensitivity: -96dBm
> Ultra-low power consumption

Application

Technical Description

LoRa Performance

LoRaWAN Protocol

V1.0.3

LoRa Frequency

MKL68BA-US915 support US915/AU915/AS923 MKL68BA-EU868 support EU868/IN865

Tx Power

Max 22 dBm

Sensitivity

Range

Up to 10km(in free space 5dBi)

Mechanical Design

Dimensions

24mm x 19mm x 2.8mm

Hardware

MCU

NRF52832

Flash

512KB

RAM

64KB

Interface

Total 34pins

Supply Voltage

3.3V

TX Current(LoRa+BLE)

Max 115mA

RX Current(LoRa+BLE)

6.4mA

Sleep current

7uA

Power Supply

1.75V to 3.6V

Bluetooth Performance

Bluetooth® (BLE)

V4.2

Frequency

2.402 - 2.480 GHz

Transmit Power

0 dBm

Range

Up to 50m in free space

Antenna Options

BLE (Internal) chip antenna

On-board ceramic chip monopole antenna-0.5 dBi

LoRa (External)

U.FL (IPEX) connector for external antenna

Application Specification

Operating Temperature

-40 ˚ C to +85 ˚ C (VCC 3.3 V)

Storage Temperature

-40 ˚ C to +85 ˚ C

CE Certifications

In progress

FCC Certifications

In progress

LoRaWAN Alliance certification

In progress

Miscellaneous

Lead-free and RoHS compliant
