B2 Smart Badge

The B2 Smart badge is designed for Staff Duress & Panic Alerting in a variety of settings, including constructions, healthcare facilities, and offices. It is a wearable badge that comes with an enlarged SOS button and features IP66 waterproofing and a high-capacity battery, making it ideal for use in any environment. Furthermore, it integrates ID card and BLE communication into an all-in-one design. Bluetooth wearable badges also have LED notifications and buzzers that enable immediate alerts and location-based services, including Geo-fenced alerts, access control, visitor traffic management, and location awareness.

Product Features

> Standard CR80 ID card can be inserted and placed on the side
> Can be worn horizontally or vertically with different lanyard options
> It can read RFID tags with HF, LF and UHF on both sides (customizable)
> Enlarged textured concave Button to activate SOS or self-defined services

> IP66 waterproof and robust casing enable it to withstand harsh environments
> 3-color LED notification and buzzer to distinguish different types of notifications
> The transmission range can reach up to 150m in an open area without obstacles
> Low power consumption and large capacity batteries allow this badge to last up to 4 year

Smart Badge Applications

Smart Healthcare

The B2 smart badge can be used in healthcare settings for duress calling, restricting access to sensitive areas, and location awareness. This feature helps healthcare workers send instant distress signals to their colleagues in case of emergencies, restrict access to sensitive areas to protect patient privacy, and track patients and staff in real-time, providing a better overview of healthcare operations.

Constructions

The B2 wearable Bluetooth badge can be used in construction sites for detecting near-misses, geo-fence alerts, and instant SOS alerts. With the bluetooth badge, companies can detect potential safety hazards, alert workers when they enter restricted areas, and instantly send distress signals in case of an emergency. This feature helps enhance safety protocols, prevent accidents, and ensure a safer work environment for all workers.

Smart Office

With the smart wearable badge, companies can easily manage the flow of visitors, monitor their movements, and ensure that they only access authorized areas. This feature helps enhance security protocols, improve visitor experience, and ensure a safer work environment. Additionally, it is a valuable smart device for tracking employee movements, attendance, and productivity.

Warehouses & Factories

With 3-axis accelerometer, B2 smart badge can detect whether the workers have fallen or are slacking off, thus improving worker safety and productivity. The B2 bluetooth badge is also useful for restricting access to sensitive areas, enhancing security protocols, and ensuring a safer work environment.

Technical Description

Connectivity

BLE 5.0

Dimensions

98x65.18x7.95mm(non-key area thickness)
98x65.18x8.55mm (key area thickness)

Color

Body - White
Button - Red (color customizable)

Material

PC+ABS

Weight

50g

IP Rating

IP66

Sensor

Accelerometer sensor | Buzzer

RFID

HF | LF/UHF(customizable)

Battery Capacity

800mAh | Non-replaceable battery

Battery Lifespan

4 years*

Operating Temperature

-20°C to 60°C

Transmission Range

150m (Open area without obstacles)

Installation

Lanyard

Suitable card size

CR80 IC Card

Certification

FCC | CE | RoHS | REACH | Bluetooth

Documentation

Type Title Date
Product Brief B2 Badge Product Brief_V1.0_20230225.pdf 2023-02-25
