H2A Location Beacon

  • IP65 Waterproof standard
  • 3M sticker and Screw assemble way is option
  • Push button with multiple functions, such as trigger notification
  • Additional Motion sensors can be advertised when object is falling or moving
  • Compatible with iBeacon™ and Eddystone™ (UID, URL, TLM) at the same time.

Description

The H2A BeaconX Pro is an indoor location beacon with a 3-axis accelerometer sensor, which can broadcast iBeacon, Eddystone, and sensor data. The H2A location beacon belongs to the H2 series of products, and can be used for beacon indoor location tracking solutions. It has a portable case, waterproof structure (IP65), accurate hardware, robust firmware, and external push buttons.

Additionally, we offer schematic diagrams for your firmware development, and also provide SDK/API for application development. Any of the parameters of the H2A location BeaconX Pro can be modified, and all the sensor data can be checked. Take a look at our BeaconX Pro app, currently available for both iOS and Android.

Features

Advertising Beacon Device

Supporting BLE5.0

Ultra-low power consumption chipset NRF52 Serise

6 Slots can be configured

Support button trigger and motion trigger

Firmware updated via DFU

G-value, sampling rate and sensitivity of 3-axis accelerometer sensor can be configured

Logo customizable (MOQ 100units)

Provided with your own configuration (MOQ 100 units)

100% Configurable Parameters via MokobeaconX Pro app (Android & iOS)

Paremeters
Size(H*W*L) 48.5 * 48.0 * 16.3mm
Battery Model CR2477
Battery Capacity (mAh) 1000mAh
Default battery Life Up to 5 years
Battery replaceable Yes
Max Range 150m(+4dBm)
Waterproof Yes IP65
Protocols iBeacon& Eddystone: UID, URL, TLM Eddystone Configuration GATT Service
Firmware updating OTA
Attachment method Landyard, 3M double side sticker, Screw
Built-in Sensor Accelerometer sensor
Certification CE & FCC

Documentation

Type Title Date
Product Datasheet H2A Navigation Beacon Product Brief - V1.2.pdf 2022-12-29
Product Specification H2A Product Specification_V1.0.pdf 2023-2-6

Display

H2A Beacon Applications

H2A location beacon

Personnel safety management:

Applications: Hotels, Prisons, etc.—anywhere you need to keep track of personnel.Fix an H2A location beacon with 3M glue or screws under the coffee table in each room of the hotel or on the wall. Each H2A location beacon broadcasts Bluetooth RSSI and different UUID and MAC addresses, conveniently using only a little power. The CR2477 button battery used in the H2A can last the device for 3-5 years.

Hotel-related staff can receive signals broadcast by the H2A location beacon through the Android & IOS mobile app to locate the nearest room. If, for some reason, staff feels they are in danger, they can press the emergency alarm button on the Android & IOS mobile app, and the relevant information will be sent via SMS (Short Message Service), immediately notifying security personnel and uploading the panic button information to the server/cloud via LTE or WIFI. Hotel managers can quickly locate their hotel room and location in the background, and notify the relevant people to help. Additionally, this alarm information will always be saved, allowing for comprehensive documentation of an incident.
