H4-P5202DH1 Beacon

Temperature & Humidity Sensor Beacon

  • IP66 Waterproof without external sensor
  • Up to 4000 historical data can be stored
  • 3-axis accelerometer sensor with motion trigger.
  • Button with SOS Trigger function
  • SHT30 T&H sensor(0℃~65℃/10%~65%) with trigger function.
  • Longer life time with 2*AAA lithium batteries
  • iBeacon & Eddystone (UID, URL, TLM) and sensor in turn.
  • All the parameters can be modified via MokobeaconX Pro
MOKOSmart Beacon-brands icon
Features
icon-2

Advertising Beacon Device

Supporting BLE5.0

Ultra-low power consumption chipset NRF52 Serise

6 Slots can be configured

Support button trigger and motion trigger

Firmware updated via DFU

G-value, sampling rate and sensitivity of 3-axis accelerometer sensor can be configured

Customizable to increase NFC to wake up bluetooth (MOQ:1000pcs)

Logo and wristband color customizable (MOQ 200units)

Provided with your own configuration (MOQ 100 units)

100% Configurable Parameters via MokobeaconX Pro app (Android & iOS)

Temperature and humidity function can be selected one of it any time

Paremeters
Size(H*W*L) 69.9 * 32.2 * 18.2mm Protocols iBeacon & Eddystone: UID, URL, TLM
Battery Model 2xAAA Lithium Battery Eddystone Configuration GATT Service
Battery Capacity (mAh) 1.5V; 1200mAh Firmware updating DFU
Default battery Life About 36 mouths with default setting Attachment method Double side tape/Laid flat
Battery replaceable Yes Built-in Sensor Motion LIS3DH; RGB LED; Buzzer
Max Range 120m(+4dBm)
Waterproof IPX4 Certification CE & FCC
Size(H*W*L) 69.9 * 32.2 * 18.2mm
Protocols iBeacon & Eddystone: UID, URL, TLM
Battery Model 2xAAA Lithium Battery
Eddystone Configuration GATT Service
Battery Capacity(mAh) 1.5V; 1200mAh
Firmware updating DFU
Default battery Life About 36 mouths with default setting
Attachment method Double side tape/Laid flat
Battery replaceable Yes
Built-in Sensor Motion LIS3DH; RGB LED; Buzzer
Max Range 120m(+4dBm)
Waterproof IPX4
Certification CE & FCC

Documentation

Type Title Date
Product Datasheet H4 Beacon Product Brief – V1.2.pdf 2022-12-29
Product Specification H4 Product Specification_v1.0.pdf 2023-2-6

H4 Beacon Display
